| Ethernet LAN features |
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Mobile network |
| SIM card slot |
Yes |
| 3G/4G USB modem compatibility |
No |
| Mobile network generation |
5G |
| 4G bands supported |
700,800,850,900,1500,1800,2100,2300,2500,2600,3500,3700 MHz |
| 3G standards |
DC-HSDPA, HSPA, HSPA+, UMTS |
| 4G standard |
LTE-TDD & LTE-FDD |
| SIM card type |
NanoSIM |
| 5G bands supported |
700,800,850,900,1800,2100,2300,2500,2600,3500,3700 MHz |
| 3G bands supported |
850,900,2100 MHz |
| Protocols |
| DMZ support |
Yes |
| Supported network protocols |
IPv4, IPv6 |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Security |
| VPN support |
PPTP VPN, IPSec VPN , OpenVPN |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall security |
IPv4 SPI Firewall, IPv6 Firewal |
| Firewall |
Yes |
| DoS attack prevention |
Yes |
| DMZ support |
Yes |
| Parental control |
Yes |
| Access Control List (ACL) |
Yes |
| Performance |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| WAN connection |
| Ethernet WAN |
Yes |
| SIM card slot |
Yes |
| 3G/4G USB modem compatibility |
No |
| WAN connection type |
RJ-45 |
| Wireless LAN features |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) |
1201 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Modulation |
1024-QAM |
| WLAN data transfer rate (first band) |
574 Mbit/s |
| WLAN data transfer rate (second band) |
1201 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Network |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| VPN support |
PPTP VPN, IPSec VPN , OpenVPN |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Port triggering |
Yes |
| Number of guest networks (5 GHz) |
1 |
| Number of guest networks (2.4 GHz) |
1 |
| Dynamic DNS (DDNS) |
Yes |
| Ports & interfaces |
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
3 |
| Management features |
| WPS push button |
Yes |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| MU-MIMO technology |
Yes |
| Design |
| Product type |
Tabletop router |
| On/off switch |
Yes |
| Product colour |
White |
| Certificates |
| Compliance certificates |
CE, RoHS |
| Software |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Packaging content |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| Antenna |
| Antenna design |
Internal |
| Detachable antenna(s) |
Yes |
| Antennas quantity |
10 |
| Power |
| Power source type |
AC |
| Output voltage |
12 V |
| Output current |
2 A |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50/60 Hz |
| Operational conditions |
| Storage temperature (T-T) |
-40 – 70 °C |
| Storage relative humidity (H-H) |
5 – 90% |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Browser supported |
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Weight & dimensions |
| Width |
99 mm |
| Height |
190 mm |
| Depth |
99 mm |
| Packaging data |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| Technical details |
| Compliance certificates |
CE, RoHS |
