| Ethernet LAN features |
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| DSL features |
| DSL WAN |
Yes |
| ADSL |
Yes |
| ADSL2 |
Yes |
| ADSL2+ |
Yes |
| VDSL |
Yes |
| VDSL2 |
Yes |
| Mobile network |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
Yes |
| Network |
| Network address translation (NAT) |
Yes |
| Guest access |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| VPN tunnels quantity |
10 |
| Port forwarding |
Yes |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Port triggering |
Yes |
| Number of guest networks (5 GHz) |
1 |
| Number of guest networks (2.4 GHz) |
1 |
| USB sharing |
Yes |
| VPN Passthrough |
Yes |
| Static route |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Protocols |
| DMZ support |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Supported network protocols |
IPv4, IPv6 |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Management features |
| Universal Plug and Play (UPnP) |
Yes |
| WPS push button |
Yes |
| Web-based management |
Yes |
| Reset button |
Yes |
| MU-MIMO technology |
Yes |
| Security |
| VPN tunnels quantity |
10 |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Network address translation (NAT) |
Yes |
| Guest access |
Yes |
| Firewall |
Yes |
| DMZ support |
Yes |
| Filtering |
Yes |
| Parental control |
Yes |
| Access Control List (ACL) |
Yes |
| Performance |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows Vista, Windows XP |
| Mac operating systems supported |
macOS |
| Linux operating systems supported |
Yes |
| Firmware upgradeable |
Yes |
| Memory card slot(s) |
No |
| Weight & dimensions |
| Package width |
318 mm |
| Package weight |
1.17 kg |
| Package height |
71 mm |
| Package depth |
240 mm |
| Width |
216 mm |
| Height |
36.8 mm |
| Depth |
164 mm |
| Certificates |
| Certification |
CE, RCM, RoHS |
| WAN connection |
| Ethernet WAN |
Yes |
| DSL WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
Yes |
| WAN connection type |
RJ-45 |
| Wireless LAN features |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
1733 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) |
1733 Mbit/s |
| WLAN data transfer rate (second band) |
300 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ports & interfaces |
| USB port |
Yes |
| RJ-11 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
3 |
| DC-in jack |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Memory card slot(s) |
No |
| Design |
| Product type |
Tabletop router |
| Wall mountable |
Yes |
| On/off switch |
Yes |
| LED indicators |
LAN, Power, Status, WLAN |
| Product colour |
Black |
| Software |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows Vista, Windows XP |
| Mac operating systems supported |
macOS |
| Linux operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Packaging content |
| Cables included |
LAN (RJ-45), Phone (RJ-11) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| Antenna |
| Antenna design |
Internal & external |
| Antennas quantity |
4 |
| Features |
| Firmware upgradeable |
Yes |
| Certification |
CE, RCM, RoHS |
| Power |
| Power source type |
DC |
| Output voltage |
12 V |
| Output current |
1.5 A |
| Operational conditions |
| Storage temperature (T-T) |
-40 – 70 °C |
| Storage relative humidity (H-H) |
5 – 90% |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows Vista, Windows XP |
| Mac operating systems supported |
macOS |
| Linux operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Packaging data |
| Package width |
318 mm |
| Package weight |
1.17 kg |
| Package height |
71 mm |
| Package depth |
240 mm |
| Cables included |
LAN (RJ-45), Phone (RJ-11) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
