| Management features |
| Switch type |
Managed |
| Quality of Service (QoS) support |
Yes |
| Multicast support |
Yes |
| Switch layer |
L2 |
| Ports & interfaces |
| SFP+ module slots quantity |
4 |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| Console port |
RJ-45/USB Type-C |
| Network |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x |
| VLAN support |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| 10G support |
Yes |
| IGMP snooping |
Yes |
| Data transmission |
| Throughput |
95 Mpps |
| Latency (1 Gbps) |
1.585 µs |
| Latency (10 Gbps) |
1.243 µs |
| Packet buffer memory |
12.38 MB |
| MAC address table |
8192 entries |
| Switching capacity |
128 Gbit/s |
| Jumbo frames support |
Yes |
| Security |
| Authentication |
MAC-based authentication, Web-based authentication |
| SSH/SSL support |
Yes |
| Security algorithms |
SSH, SSH-2 |
| IGMP snooping |
Yes |
| Access Control List (ACL) |
Yes |
| Authentication type |
RADIUS, TACACS+ |
| DHCP features |
DHCP client |
| Multicast features |
| Multicast support |
Yes |
| Design |
| Form factor |
1U |
| Product colour |
Black |
| Stackable |
No |
| Rack mounting |
Yes |
| Performance |
| Processor frequency |
1016 MHz |
| Memory type |
DDR3-SDRAM |
| Internal memory |
4096 MB |
| Flash memory |
32000 MB |
| Built-in processor |
Yes |
| Processor model |
ARM Cortex-A9 |
| Packet buffer memory |
12.38 MB |
| Stackable |
No |
| Harmonized System (HS) code |
85176990 |
| Power |
| Power supply included |
No |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
240 W |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Storage relative humidity (H-H) |
5 – 95% |
| Operating temperature (T-T) |
-40 – 70 °C |
| Operating relative humidity (H-H) |
5 – 95% |
| Operating altitude |
0 – 4200 m |
| Non-operating altitude |
0 – 4600 m |
| Virtual LAN features |
| VLAN support |
Yes |
| Weight & dimensions |
| Width |
444.5 mm |
| Depth |
304.4 mm |
| Height |
44 mm |
| Weight |
6.47 kg |
| Technical details |
| Form factor |
1U |
| Product colour |
Black |
| Stackable |
No |
| Processor frequency |
1016 MHz |
| Rack mounting |
Yes |
| Built-in processor |
Yes |
| Memory |
| Packet buffer memory |
12.38 MB |
| Memory type |
DDR3-SDRAM |
| Internal memory |
4096 MB |
| Flash memory |
32000 MB |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
