| Management features |
| Multicast support |
Yes |
| Switch type |
Managed |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| MIB support |
Yes |
| Switch layer |
L2 |
| Network |
| IGMP snooping |
Yes |
| Auto-sensing |
Yes |
| Networking standards |
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x |
| Full duplex |
Yes |
| VLAN support |
Yes |
| Spanning tree protocol |
Yes |
| Rate limiting |
Yes |
| Port mirroring |
Yes |
| Link aggregation |
Yes |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| 10G support |
No |
| Virtual LAN features |
| VLAN support |
Yes |
| Performance |
| Packet buffer memory |
1 MB |
| Stackable |
Yes |
| Processor frequency |
400 MHz |
| Memory type |
SDRAM |
| Internal memory |
512 MB |
| Flash memory |
4 MB |
| Built-in processor |
Yes |
| Processor model |
PowerPC MPC8313 |
| Technical details |
| Form factor |
1U |
| Product colour |
Grey |
| Stackable |
Yes |
| Processor frequency |
400 MHz |
| Rack mounting |
Yes |
| Electromagnetic immunity |
EN 55024, CISPR 24; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2, IEC 61000-3-2; EN 61000-3-3, IEC 61000-3-3 |
| Built-in processor |
Yes |
| Ports & interfaces |
| SFP module slots quantity |
2 |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| Gigabit Ethernet (copper) ports quantity |
2 |
| Console port |
RJ-45 |
| Data transmission |
| Throughput |
9.5 Mpps |
| Latency (10-100 Mbps) |
8.3 µs |
| Latency (1 Gbps) |
2.9 µs |
| Packet buffer memory |
1 MB |
| MAC address table |
16000 entries |
| Switching capacity |
12.8 Gbit/s |
| Jumbo frames support |
Yes |
| Security |
| SSH/SSL support |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP server, DHCP client |
| Multicast features |
| Multicast support |
Yes |
| Protocols |
| Management protocols |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SMON, CLI |
| Certificates |
| Safety |
EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950 |
| Electromagnetic compatibility |
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A |
| Memory |
| Packet buffer memory |
1 MB |
| Memory type |
SDRAM |
| Internal memory |
512 MB |
| Flash memory |
4 MB |
| Design |
| Safety |
EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950 |
| Form factor |
1U |
| Product colour |
Grey |
| Stackable |
Yes |
| Electromagnetic compatibility |
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A |
| Rack mounting |
Yes |
| Power |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Power consumption (typical) |
22.1 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Operational conditions |
| Operating temperature (T-T) |
0 – 55 °C |
| Heat dissipation |
95 BTU/h |
| Weight & dimensions |
| Width |
443 mm |
| Depth |
254 mm |
| Height |
43.9 mm |
| Weight |
2.59 kg |
| Other features |
| Electromagnetic immunity |
EN 55024, CISPR 24; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2, IEC 61000-3-2; EN 61000-3-3, IEC 61000-3-3 |
