| Gigabit Ethernet ports |
16 |
| Uplink interfaces |
2 SFP |
| PoE+power budget |
120W |
| Fanless |
Y |
| Dimensions (WxDxH in inches) |
10.56 x 8.26x 1.73 |
|
| RJ-45 Ethernet |
1 |
| USB mini-B |
1 |
| USB-A port for storage and Bluetooth console |
1 |
|
| CPU |
ARM v7 800 MHz |
| DRAM |
512 MB |
| Flash memory |
256 MB |
|
| Forwarding bandwidth |
18 Gbps |
| Switching bandwidth |
36 Gbps |
| Forwarding rate(64—byte L3 packets) |
26.78 Mpps |
| Unicast MAC addresses |
16000 |
| IPv4 unicast direct routes |
542 |
| IPv4 unicast indirect routes |
256 |
| IPv6 unicast direct routes |
414 |
| IPv6 unicast indirect routes |
128 |
| IPv4 static routes |
16 |
| IPv6 static routes |
16 |
| IPv4 multicast routes and IGMP groups |
1024 |
| IPv6 multicast groups |
1024 |
| IPv4/MAC security ACEs |
600 |
| IPv6 security ACEs |
600 |
| Maximum active VLANs |
256 |
| VLAN IDs available |
4094 |
| Maximum STP instances |
64 |
| Maximum SPAN sessions |
4 |
| MTU-L3 packet |
9198 bytes |
| Jumbo Ethernet frame |
10,240 bytes |
| Dying Gasp |
Yes |
| MTBF in hours (data) |
2,165,105 |
| MTBF in hours (PoE) |
706,983 |
| MTBF in hours (Full PoE) |
\ |
|
| Operating temperature Seal level |
-5 to 50 °C* |
| Up to 5,000ft (1500 m) |
-5 to 45 °C |
| Upto 10,000 (3000 m) |
-5 to 40 °C |
| Operating altitude |
10,000 ft (3,000m) |
| Operating relative humidity |
5% to 90% at 40°C |
| Storage temperature |
-13 to 158°C (-25 to 70°C) |
| Storage altitude |
15,000 ft (4500m) |
| Storage relative humidity |
5% to 95% at 65°C |
