| Management features |
| Switch type |
Managed |
| Quality of Service (QoS) support |
Yes |
| Multicast support |
Yes |
| Ports & interfaces |
| SFP module slots quantity |
24 |
| Networking |
| Networking standards |
IEEE 802.11ac,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| VLAN support |
Yes |
| Spanning tree protocol |
Yes |
| Routing entries |
24000 |
| Rate limiting |
Yes |
| Link aggregation |
Yes |
| IP routing |
Yes |
| IGMP snooping |
Yes |
| Data transmission |
| MAC address table |
32000 entries |
| Number of VLANs |
4000 |
| Jumbo frames support |
Yes |
| Security |
| Security algorithms |
802.1x RADIUS |
| Access Control List (ACL) |
Yes |
| Protocols |
| Management protocols |
SNMP v1, SNMP v2c, SNMP v3 |
| Design |
| Safety |
UL 60950-1, CAN/CSA-C22.2, EN 60950-1, IEC 60950-1, GOST, NOM |
| Colour of product |
Black, Grey |
| LED indicators |
Yes |
| Electromagnetic compatibility |
47CFR, AS/NZS CISPR22 2, CISPR22, EN55022, ICES003, EN61000-3-2, KCC, EN55024, KN24 |
| Certification |
RoHS |
| Rack mounting |
Yes |
| Performance |
| Stackable |
Yes |
| Memory type |
DRAM |
| Internal memory |
4096 MB |
| Flash memory |
2048 MB |
| Power |
| AC input voltage |
100-240 V |
| Output power |
350 W |
| Number of power supply units |
1 |
| Technical details |
| Colour of product |
Black, Grey |
| Stackable |
Yes |
| Rack mounting |
Yes |
| Certificates |
| Safety |
UL 60950-1, CAN/CSA-C22.2, EN 60950-1, IEC 60950-1, GOST, NOM |
| Electromagnetic compatibility |
47CFR, AS/NZS CISPR22 2, CISPR22, EN55022, ICES003, EN61000-3-2, KCC, EN55024, KN24 |
| Certification |
RoHS |
| Memory |
| Memory type |
DRAM |
| Internal memory |
4096 MB |
| Flash memory |
2048 MB |
| Indication |
| LED indicators |
Yes |
| Packaging content |
| User guide |
Yes |
| System requirements |
| Compatibility |
Aironet 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Operational conditions |
| Storage temperature (T-T) |
-40 – 70 °C |
| Operating temperature (T-T) |
-5 – 45 °C |
| Weight & dimensions |
| Width |
445 mm |
| Depth |
445 mm |
| Packaging data |
| User guide |
Yes |
