Description
Cisco Catalyst 2960-XR series switches offer power resiliency with optional dual field-replaceable power supplies and IP Lite Cisco IOS software with dynamic routing and Layer 3 features. WS-C2960XR-48FPD-I is one of 2960-XR switches, IP Lite switch, supporting forty-eight 10/100/1000 Ethernet ports with POE+ and two 10G SFP+ uplink interfaces. IP Lite Image enables basic access layer 3 routing features, such as RIPV1, V2, OSPF stub, EIGRP stub, HSRP, VRRP, PIM stub, etc.
Specifications
| Product Code | WS-C2960XR-48FPD-I |
| Enclosure Type | Rack-mountable – 1U |
| Feature Set | IP Lite |
| Uplink Interfaces | 2 x 10G SFP+ |
| Ports | 48 x 10/100/1000 (POE+) |
| Available PoE Power | 740W |
| Forwarding Bandwidth | 108Gbps |
| Maximum stacking number | 8 |
| Stack bandwidth | 80G |
| Switching Bandwidth | 216Gbps |
| RAM | 512 MB |
| Flash Memory | 128 MB |
| Dimensions | 44.5 cm x 40.8 cm x 4.45 cm |
