| Power |
| Output power |
2700 W |
| Input operation voltage (min) |
151 V |
| Input operation voltage (max) |
302 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Surge energy rating |
365 J |
| Efficiency |
98.4% |
| Emergency Power Off (EPO) |
Yes |
| Output power capacity |
3 kVA |
| Ports & interfaces |
| Cable length |
1.83 m |
| USB port |
Yes |
| SmartSlot |
Yes |
| AC outlets quantity |
9 AC outlet(s) |
| AC outlet types |
C13 coupler, C19 coupler |
| Power plug |
C20 coupler |
| Number of output IEC jumpers |
2 |
| Performance |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Auto-restart |
Yes |
| Automatic Voltage Regulation (AVR) |
Yes |
| LED indicators |
Status |
| Noise level |
53 dB |
| Audible alarm(s) |
Yes |
| Features |
| Output frequency |
50/60 Hz |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Auto-restart |
Yes |
| Automatic Voltage Regulation (AVR) |
Yes |
| Output power |
2700 W |
| Input operation voltage (min) |
151 V |
| Input operation voltage (max) |
302 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Surge energy rating |
365 J |
| Efficiency |
98.4% |
| Emergency Power Off (EPO) |
Yes |
| Noise level |
53 dB |
| Audible alarm(s) |
Yes |
| Output power capacity |
3 kVA |
| Input frequency |
50/60 Hz |
| Battery |
| Battery life (max) |
5 year(s) |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery recharge time |
3 h |
| Typical backup time at half load |
17.2 min |
| Typical backup time at full load |
5.1 min |
| Hot-swap battery |
Yes |
| Cold start |
Yes |
| Automatic battery test |
Yes |
| Design |
| Form factor |
Tower |
| LED indicators |
Status |
| Product colour |
Black |
| Certification |
CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI |
| Cable length |
1.83 m |
| Display type |
LCD |
| Operational conditions |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-15 – 45 °C |
| Operating relative humidity (H-H) |
0 – 95% |
| Storage relative humidity (H-H) |
0 – 95% |
| Operating altitude |
0 – 3000 m |
| Non-operating altitude |
0 – 15000 m |
| Technical details |
| Output frequency |
50/60 Hz |
| Sustainability certificates |
Green Premium |
| Harmonized System (HS) code |
85078000 |
| Total carbon footprint (kg of CO2e) |
3335.07 |
| Compliance certificates |
RoHS |
| Certificates |
| Certification |
CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI |
| Compliance certificates |
RoHS |
| Packaging content |
| Quick installation guide |
Yes |
| Cables included |
RS-232, USB cable |
| Sustainability |
| Sustainability certificates |
Green Premium |
| Weight & dimensions |
| Package width |
381 mm |
| Package depth |
762 mm |
| Package height |
699 mm |
| Weight |
52.5 kg |
| Width |
197 mm |
| Package weight |
63.7 kg |
| Height |
435 mm |
| Depth |
544 mm |
| Packaging data |
| Quick installation guide |
Yes |
| Cables included |
RS-232, USB cable |
| Package width |
381 mm |
| Package depth |
762 mm |
| Package height |
699 mm |
| Package weight |
63.7 kg |
| Logistics data |
| Products per pallet |
9 pc(s) |
| Harmonized System (HS) code |
85078000 |
| Total carbon footprint (kg of CO2e) |
3335.07 |
