Data transmission |
SSL performance |
60 transactions/sec |
IPSec VPN throughput |
100 Gbit/s |
Firewall throughput |
1.8 Gbit/s |
VPN throughput |
0.45 Gbit/s |
Firewall throughput |
1800 Mbit/s |
VPN throughput |
450 Mbit/s |
Performance |
Mean time between failures (MTBF) |
529688.2 h |
Heat dissipation |
45.38 BTU/h |
Certification |
DCC, CE, C-Tick, LVD |
Network |
Active TCP connections (max) |
600000 |
Number of VLANs |
16 |
Concurrent SSL/VPN connections (maximum) |
200 |
Concurrent SSL/VPN connections (default) |
60 |
Security |
Security algorithms |
IPSEC, SSL/TLS |
VPN support |
IKEv2, IPSec, SSL, L2TP/IPSec |
Management features |
URL filtering |
Yes |
Ports & interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
SFP module slots quantity |
1 |
Ethernet DMZ ports quantity |
4 |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Console port |
DB9 |
Number of console ports |
1 |
Design |
Built-in fan |
No |
Power |
Input current |
2.5 A |
Power consumption (max) |
13.3 W |
Certificates |
Certification |
DCC, CE, C-Tick, LVD |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-30 – 70 °C |
Operating relative humidity (H-H) |
10 – 90% |
Storage relative humidity (H-H) |
10 – 90% |
Weight & dimensions |
Weight |
1.4 kg |
Width |
272 mm |
Depth |
187 mm |
Height |
36 mm |
Packaging data |
Package width |
427 mm |
Package height |
247 mm |
Package depth |
73 mm |
Technical details |
Heat dissipation |
45.38 BTU/h |
Harmonized System (HS) code |
85176990 |
Endurance |
Mean time between failures (MTBF) |
529688.2 h |
Other features |
Firewall throughput |
1800 Mbit/s |
VPN throughput |
450 Mbit/s |
Logistics data |
Harmonized System (HS) code |
85176990 |
