Design |
LED indicators |
Yes |
Mounting type |
Rack mounting |
Rack capacity |
1U |
Product colour |
Black |
Features |
Voice codecs |
G.711, G.722, G.723, G.726, G.729A |
Performance |
Control display unit |
No |
Mounting type |
Rack mounting |
Rack capacity |
1U |
Product colour |
Black |
Data transmission |
Static route |
Yes |
Protocols |
Management protocols |
SNMP, RADIUS, TR-069 |
Supported network protocols |
FTP, TFTP, HTTP, HTTPS, SSH |
Supported protocols |
SIP (RFC3261), IAX2 UDP, TCP, TLS, SRTP |
Network |
Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3u |
Dynamic DNS (DDNS) |
Yes |
Ethernet LAN data rates |
10,100 Mbit/s |
Supported resolutions |
SIP (RFC3261), IAX2 UDP, TCP, TLS, SRTP |
Differentiated services (DiffServ) supported |
Yes |
Security |
VLAN support |
Yes |
Firewall security |
Yes |
Network address translation (NAT) |
Yes |
Ports & interfaces |
Foreign eXchange Station (FXS) ports quantity |
4 |
Ethernet LAN (RJ-45) ports |
1 |
RJ-11 ports quantity |
4 |
Management features |
Syslog |
Yes |
Quality of Service (QoS) support |
Yes |
Power |
Output voltage |
12 V |
Output current |
1 A |
Weight & dimensions |
Width |
200 mm |
Height |
25 mm |
Depth |
137 mm |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-20 – 65 °C |
Operating relative humidity (H-H) |
10 – 90% |
Technical details |
Voice codecs |
G.711, G.722, G.723, G.726, G.729A |
Harmonized System (HS) code |
85176990 |
Indication |
LED indicators |
Yes |
Display |
Control display unit |
No |
Logistics data |
Harmonized System (HS) code |
85176990 |
