| Specification |
| Technical details |
| Device type |
Cellular network router |
| Data network |
3G, 4G, HSUPA, LTE, WCDMA |
| Package width |
355 mm |
| Package height |
175 mm |
| Package depth |
60 mm |
| Harmonized System (HS) code |
85176990 |
| Ethernet LAN features |
| Ethernet LAN (RJ-45) ports |
5 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Auto MDI/MDI-X |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Networking standards |
IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| DHCP server |
Yes |
| DHCP client |
Yes |
| IP routing |
Yes |
| Cellular interface |
| Number of SIM cards |
2 |
| 3G standards |
DC-HSDPA, HSUPA, WCDMA |
| 4G standard |
LTE |
| Design |
| Housing material |
Steel |
| Device type |
Cellular network router |
| Product colour |
Grey |
| Reset button |
Yes |
| LED indicators |
Data, Power, Signal strength, Status, WAN |
| Wireless LAN features |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rates supported |
867 Mbit/s |
| Wi-Fi frequency |
5 GHz |
| Mobile network |
| Number of SIM cards |
2 |
| Data network |
3G, 4G, HSUPA, LTE, WCDMA |
| Short Message Service (SMS) |
Yes |
| 3G standards |
DC-HSDPA, HSUPA, WCDMA |
| 4G standard |
LTE |
| SIM card type |
MiniSIM |
| Ports & interfaces |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
5 |
| USB port |
Yes |
| USB port type |
USB Type-A |
| Serial interface |
| Serial interface type |
RS-232 |
| Security |
| Port forwarding |
Yes |
| Security algorithms |
AES-CCMP, HTTPS, SSH, SSL/TLS, TLS, WEP, WPA2-EAP, WPA2-Enterprise, WPA2-PSK |
| Network address translation (NAT) |
Yes |
| Firewall |
Yes |
| URL filtering |
Yes |
| DMZ support |
Yes |
| VPN support |
DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC |
| Material |
| Housing material |
Steel |
| Performance |
| Built-in processor |
Yes |
| Processor frequency |
0.717 GHz |
| RAM capacity |
0.256 GB |
| RAM type |
DDR3 |
| Internal storage capacity |
0.256 GB |
| Management features |
| Web-based management |
Yes |
| Antenna |
| Antenna type |
External |
| Detachable antenna(s) |
Yes |
| Power |
| Power source type |
DC |
| Output voltage |
9 – 50 V |
| Operational conditions |
| Operating temperature (T-T) |
-40 – 75 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| Weight & dimensions |
| Weight |
1.05 kg |
| Width |
272 mm |
| Depth |
122.6 mm |
| Height |
43.7 mm |
| Packaging data |
| Package width |
355 mm |
| Package height |
175 mm |
| Package depth |
60 mm |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
|
