Specification |
Technical details |
Device type |
Cellular network router |
Data network |
LTE |
Ethernet LAN features |
Ethernet LAN (RJ-45) ports |
5 |
Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL), DLNA |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Auto MDI/MDI-X |
Yes |
Ethernet LAN |
Yes |
Ethernet LAN interface type |
Gigabit Ethernet |
DHCP client |
Yes |
Cellular interface |
4G standard |
LTE |
Network |
Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL), DLNA |
Design |
Housing material |
Aluminium |
Device type |
Cellular network router |
Product colour |
Silver |
Reset button |
Yes |
LED indicators |
Power, Status, WAN |
Wireless LAN features |
Wi-Fi |
Yes |
Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Mobile network |
Data network |
LTE |
Short Message Service (SMS) |
Yes |
4G standard |
LTE |
Ports & interfaces |
USB 2.0 ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
5 |
USB port |
Yes |
Security |
Security algorithms |
AES-CCMP, TKIP, WEP, WPA2-Enterprise, WPA2-PSK, WPA3-SAE |
Firewall |
Yes |
GPS Performance |
Embedded GNSS |
Yes |
Material |
Housing material |
Aluminium |
Performance |
Web-based management |
Yes |
Antenna type |
External |
Antennas quantity |
8 |
Built-in processor |
Yes |
Processor frequency |
0.717 GHz |
RAM capacity |
0.256 GB |
RAM type |
DDR3 |
Internal storage capacity |
0.256 GB |
Management features |
Web-based management |
Yes |
Antenna |
Antenna type |
External |
Antennas quantity |
8 |
Power |
Power source type |
DC |
Operational conditions |
Operating temperature (T-T) |
-40 – 75 °C |
Operating relative humidity (H-H) |
10 – 90% |
Weight & dimensions |
Weight |
515 g |
Width |
132 mm |
Depth |
95 mm |
Height |
44 mm |
|
