| Specification |
| Technical details |
| Device type |
Cellular network router |
| Data network |
3G, 4G, LTE |
| Compliance certificates |
CB, CE, EAC, UKCA |
| Ethernet LAN features |
| Ethernet LAN (RJ-45) ports |
4 |
| Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Auto MDI/MDI-X |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3u |
| Cellular interface |
| Number of SIM cards |
2 |
| 4G standard |
LTE |
| Network |
| Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| Design |
| Housing material |
Aluminium |
| Device type |
Cellular network router |
| Product colour |
Black |
| Reset button |
Yes |
| Wireless LAN features |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Mobile network |
| Number of SIM cards |
2 |
| Data network |
3G, 4G, LTE |
| Short Message Service (SMS) |
Yes |
| 4G standard |
LTE |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| Security |
| Security algorithms |
AES-CCMP, SNMPv2, SNMPv3, SSID, TKIP, WPA-PSK, WPA2-EAP, WPA2-PSK, WPA3-EAP, WPA3-SAE |
| Network address translation (NAT) |
Yes |
| Firewall |
Yes |
| DMZ support |
Yes |
| VPN support |
DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256 |
| Certificates |
| Compliance certificates |
CB, CE, EAC, UKCA |
| Packaging content |
| User guide |
Yes |
| Material |
| Housing material |
Aluminium |
| Performance |
| Antenna connector type |
SMA/RP-SMA |
| Operating system installed |
RutOS |
| Antenna type |
External |
| Antennas quantity |
4 |
| Built-in processor |
Yes |
| Processor manufacturer |
Mediatek |
| Processor frequency |
0.58 GHz |
| RAM capacity |
0.128 GB |
| RAM type |
DDR2 |
| Antenna |
| Antenna connector type |
SMA/RP-SMA |
| Antenna type |
External |
| Antennas quantity |
4 |
| Power |
| Power source type |
DC |
| Operational conditions |
| Operating temperature (T-T) |
-40 – 75 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| Weight & dimensions |
| Weight |
297 g |
| Width |
110 mm |
| Depth |
100 mm |
| Height |
50 mm |
| Packaging data |
| User guide |
Yes |
|
