Specification |
Technical details |
Built-in display |
No |
Mounting |
DIN-rail |
Device type |
Cellular network router |
Data network |
2G, 3G, 4G |
Harmonized System (HS) code |
85176990 |
Ethernet LAN features |
Ethernet LAN (RJ-45) ports |
1 |
Ethernet LAN data rates |
10,100 Mbit/s |
Auto MDI/MDI-X |
Yes |
Ethernet LAN |
Yes |
Ethernet LAN interface type |
Fast Ethernet |
Networking standards |
IEEE 802.3, IEEE 802.3u |
Cellular interface |
Number of SIM cards |
1 |
4G standard |
LTE |
2G bands supported |
900,1800 MHz |
3G bands supported |
850,900,2100 MHz |
4G bands supported |
2300,2500,2600 MHz |
Design |
Built-in display |
No |
Mounting |
DIN-rail |
Housing material |
Aluminium, Plastic |
Device type |
Cellular network router |
Product colour |
Black |
Market positioning |
Industrial |
Reset button |
Yes |
LED indicators |
Yes |
Wireless LAN features |
Wi-Fi |
Yes |
Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Mobile network |
Number of SIM cards |
1 |
Data network |
2G, 3G, 4G |
Short Message Service (SMS) |
Yes |
4G standard |
LTE |
2G bands supported |
900,1800 MHz |
3G bands supported |
850,900,2100 MHz |
4G bands supported |
2300,2500,2600 MHz |
Ports & interfaces |
Ethernet LAN (RJ-45) ports |
1 |
Security |
Port forwarding |
Yes |
Security algorithms |
HTTPS, SSH, SSL/TLS, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
Network address translation (NAT) |
Yes |
Firewall |
Yes |
DMZ support |
Yes |
Material |
Housing material |
Aluminium, Plastic |
Performance |
Web-based management |
Yes |
Antenna connector type |
SMA |
Antenna type |
External |
Antennas quantity |
3 |
Built-in processor |
Yes |
Processor frequency |
0.58 GHz |
RAM capacity |
0.128 GB |
Management features |
Web-based management |
Yes |
Antenna |
Antenna connector type |
SMA |
Antenna type |
External |
Antennas quantity |
3 |
Power |
Power source type |
DC |
Output voltage |
9 – 30 V |
Operational conditions |
Operating temperature (T-T) |
-40 – 75 °C |
Operating relative humidity (H-H) |
10 – 90% |
Weight & dimensions |
Weight |
125 g |
Width |
83 mm |
Depth |
74 mm |
Height |
25 mm |
Logistics data |
Harmonized System (HS) code |
85176990 |
|
Meta Description |
1 x WAN port, 1 x LAN port, 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps, IEEE 802.11b/g/n, Europe, the Middle East, Africa, Korea, Thailand |
