Technical details |
Form factor |
Desktop |
Heat dissipation |
44.7 BTU/h |
Harmonized System (HS) code |
85176990 |
Data transmission |
Firewall throughput |
4000 Mbit/s |
IPS/IDS throughput |
2500 Mbit/s |
Maximum firewall connections per second |
16000 |
SSL inspection throughput |
750 Mbit/s |
IPSec VPN throughput |
1.8 Gbit/s |
Maximum connections (DPI) |
400000 |
Maximum connections (SPI) |
1250000 |
Firewall throughput |
4 Gbit/s |
Performance |
Heat dissipation |
44.7 BTU/h |
Network |
Point-to-point protocol over Ethernet (PPPoE) |
Yes |
Wi-Fi |
No |
VPN tunnels quantity |
200 |
Local user database |
250 |
Quality of Service (QoS) support |
Yes |
Number of VLANs |
256 |
DHCP server |
Yes |
Number of LAN Access Points (max) |
32 |
Protocols |
Routing protocols |
BGP, OSPF, RIP-1, RIP-2 |
Display |
Built-in display |
No |
Management features |
LED indicators |
Yes |
Hard drive |
Total storage capacity |
32 GB |
Ports & interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
Installed SFP+ modules quantity |
2 |
Gigabit Ethernet (copper) ports quantity |
8 |
Connectivity technology |
Wired |
WAN connection |
Mobile network (USB) |
Ethernet LAN (RJ-45) ports |
8 |
Ethernet LAN data rates |
1000,5000 Mbit/s |
Console port |
RJ-45 |
Number of console ports |
1 |
Storage |
Total storage capacity |
32 GB |
Design |
Form factor |
Desktop |
Built-in display |
No |
Power |
AC input voltage |
100-240 V |
AC input frequency |
50 – 60 Hz |
Redundant power supply (RPS) support |
Yes |
Power supply |
60 W |
Power consumption (max) |
13.4 W |
Features |
SSL inspection throughput |
750 Mbit/s |
Logistics data |
Harmonized System (HS) code |
85176990 |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-40 – 70 °C |
Operating relative humidity (H-H) |
5 – 95% |
Storage relative humidity (H-H) |
5 – 95% |
Weight & dimensions |
Weight |
970 g |
Width |
225 mm |
Depth |
150 mm |
Height |
35 mm |
Other features |
Firewall throughput |
4000 Mbit/s |
