Data transmission |
Firewall throughput |
3500 Mbit/s |
IPS/IDS throughput |
2000 Mbit/s |
Maximum firewall connections per second |
12000 |
Maximum firewall connections |
1000000 |
IPSec VPN throughput |
1500 Gbit/s |
Maximum connections (DPI) |
250000 |
Maximum connections (SPI) |
1000000 |
VoIP |
Yes |
Load balancing |
Yes |
Firewall throughput |
3.5 Gbit/s |
Network |
VPN tunnels quantity |
150 |
Local user database |
250 |
Quality of Service (QoS) support |
Yes |
DHCP server |
Yes |
Static route |
Yes |
Security |
Firewall security |
Yes |
DDoS protection |
Yes |
Deep Packet Inspection (DPI) |
Yes |
Stateful Packet Inspection (SPI) |
Yes |
Protocols |
Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS |
Management features |
LED indicators |
Yes |
Management platform |
SonicOS 7.0 |
URL filtering |
Yes |
Ports & interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
Installed SFP+ modules quantity |
2 |
Connectivity technology |
Wired |
Ethernet LAN (RJ-45) ports |
8 |
Ethernet LAN data rates |
1000 Mbit/s |
Number of console ports |
1 |
Power |
AC input frequency |
50 – 60 Hz |
Input current |
3 A |
Technical details |
Harmonized System (HS) code |
85176990 |
Logistics data |
Harmonized System (HS) code |
85176990 |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Operating relative humidity (H-H) |
5 – 95% |
Weight & dimensions |
Width |
35 mm |
Depth |
135 mm |
Height |
190 mm |
Other features |
Firewall throughput |
3500 Mbit/s |
