Technical details |
Rack mounting |
Yes |
Form factor |
1U |
Harmonized System (HS) code |
85176990 |
Data transmission |
Firewall throughput |
36000 Mbit/s |
VPN throughput |
19000 Mbit/s |
Maximum firewall connections per second |
153000 |
Maximum firewall connections |
8000000 |
Firewall throughput |
36 Gbit/s |
VPN throughput |
19 Gbit/s |
Network |
Wi-Fi |
No |
VPN tunnels quantity |
6000 |
Local user database |
3200 |
Quality of Service (QoS) support |
Yes |
DHCP server |
Yes |
DHCP client |
Yes |
Security |
Security algorithms |
3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1 |
Protocols |
Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
Routing protocols |
BGP, BGP4, OSPF, RIP, RIP-1, RIP-2 |
Management features |
LED indicators |
Yes |
Ports & interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
Installed SFP+ modules quantity |
4 |
Number of console ports |
1 |
Design |
Rack mounting |
Yes |
Form factor |
1U |
Power |
AC input frequency |
50 – 60 Hz |
Logistics data |
Harmonized System (HS) code |
85176990 |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-40 – 70 °C |
Operating relative humidity (H-H) |
5 – 95% |
Storage relative humidity (H-H) |
5 – 95% |
Weight & dimensions |
Width |
430 mm |
Depth |
465 mm |
Height |
45 mm |
Other features |
Firewall throughput |
36000 Mbit/s |
VPN throughput |
19000 Mbit/s |
