Data transmission |
Maximum data transfer rate |
867 Mbit/s |
Maximum transfer distance |
10000 m |
Antenna |
Antenna gain level (max) |
3 dBi |
Antenna design |
External |
Wireless LAN features |
Frequency band |
5 GHz |
Antenna gain level (max) |
3 dBi |
Wi-Fi |
Yes |
Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
Network |
Ethernet LAN |
Yes |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Ethernet LAN interface type |
Gigabit Ethernet |
Frequency band |
5 GHz |
Ports & interfaces |
Ethernet LAN |
Yes |
Connectivity technology |
Wired |
Ethernet LAN (RJ-45) ports |
2 |
DC-in jack |
Yes |
Features |
Product type |
Network bridge |
Product colour |
White |
Surge protection |
Yes |
International Protection (IP) code |
IP55 |
LED indicators |
LAN, Signal strength, System |
Power |
Power source type |
DC, PoE |
DC input voltage |
12 V |
Power over Ethernet (PoE) |
Yes |
Power over Ethernet (PoE) voltage |
24 V |
Operational conditions |
Operating temperature (T-T) |
-40 – 80 °C |
Operating relative humidity (H-H) |
5 – 95% |
Storage temperature (T-T) |
40 – 85 °C |
Operating temperature (T-T) |
-22 – 185 °F |
Management features |
LED indicators |
LAN, Signal strength, System |
Certificates |
Compliance certificates |
CE |
Technical details |
Product colour |
White |
Operating temperature (T-T) |
-22 – 185 °F |
Compliance certificates |
CE |
Weight & dimensions |
Width |
200 mm |
Depth |
98.5 mm |
Height |
29 mm |
