Brand: IBM
Part # 7945-52G
Condition: New
Availability: In Stock
Fill in the details Below For Discounted Price
| Processor | |
|---|---|
| Thermal Monitoring Technologies | No |
| Thermal Design Power (TDP) | 80 W |
| Tcase | 76.2 °C |
| Supported instruction sets | SSE4.2 |
| Stepping | B1 |
| Processor threads | 12 |
| Processor package size | 42.5 X 45 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 32 nm |
| Processor codename | Westmere EP |
| Physical Address Extension (PAE) | 40 bit |
| Number of QPI links | 2 |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 800,1066,1333 MHz |
| Memory channels supported by processor | Triple |
| Memory bandwidth supported by processor (max) | 32 GB/s |
| Maximum internal memory supported by processor | 288 GB |
| Idle States | Yes |
| FSB Parity | No |
| Execute Disable Bit | Yes |
| Embedded options available | Yes |
| ECC supported by processor | Yes |
| Bus type | QPI |
| Processor cache type | Smart Cache |
| Processor cache | 12 MB |
| CPU multiplier (bus/core ratio) | 18 |
| Conflict-Free processor | No |
| Processor series | Intel Xeon 5600 Series |
| Processor frequency | 2.4 GHz |
| Processor boost frequency | 2.67 GHz |
| Number of processors installed | 1 |
| Processor model | E5645 |
| System bus rate | 5.86 GT/s |
| Processor socket | Socket B (LGA 1366) |
| Processor cores | 6 |
| Processor manufacturer | Intel |
| Maximum number of SMP processors | 2 |
| Processor family | Intel® Xeon® 5000 Sequence |
| Memory | |
| Internal memory | 4 GB |
| Memory layout (slots x size) | 1 x 4 GB |
| Memory slots | 18x DIMM |
| Maximum internal memory | 192 GB |
| Internal memory type | DDR3-SDRAM |
| ECC | Yes |
| Storage | |
| Hot-swap | Yes |
| Total storage capacity | 0 GB |
| Number of HDDs installed | 0 |
| RAID support | Yes |
| Maximum storage capacity | 9.6 TB |
| Internal drive bays | 9 |
| HDD size | 2.5″ |
| HDD interface | Serial ATA, Serial Attached SCSI (SAS) |
| Graphics | |
| Maximum graphics card memory | 16 MB |
| Graphics card memory type | GDDR2 |
| Graphics card family | Matrox |
| Graphics card | G200eV |
| Network | |
| Networking features | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots | |
| PCI slots | 4 |
| PCI Express x8 slots | 4 |
| Design | |
| Chassis type | Rack (2U) |
| Performance | |
| Compatible operating systems | Microsoft Windows Server 2008 R2; Microsoft Windows Server 2008, Datacenter x64 Edition; Microsoft Windows Server 2008, Enterprise x64 Edition; Microsoft Windows Server 2008, Standard x64 Edition; Microsoft Windows Server 2008, Web x64 Edition; Windows Small Business Server 2008 Premium Edition; Windows Small Business Server 2008 Standard Edition; SUSE Linux Enterprise Server 11 AMD64/EM64T; SUSE Linux Enterprise Server 11 w/ Xen AMD64/EM64T; VMware ESX 4.1; VMware ESXi 4.1. |
| Operating system installed | No |
| Software | |
| Compatible operating systems | Microsoft Windows Server 2008 R2; Microsoft Windows Server 2008, Datacenter x64 Edition; Microsoft Windows Server 2008, Enterprise x64 Edition; Microsoft Windows Server 2008, Standard x64 Edition; Microsoft Windows Server 2008, Web x64 Edition; Windows Small Business Server 2008 Premium Edition; Windows Small Business Server 2008 Standard Edition; SUSE Linux Enterprise Server 11 AMD64/EM64T; SUSE Linux Enterprise Server 11 w/ Xen AMD64/EM64T; VMware ESX 4.1; VMware ESXi 4.1. |
| Operating system installed | No |
| Processor special features | |
| Intel® Wireless Display (Intel® WiDi) | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 1.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | No |
| Intel Enhanced Halt State | Yes |
| Intel Demand Based Switching | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel Clear Video Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel FDI Technology | No |
| Intel Dual Display Capable Technology | No |
| Intel Fast Memory Access | No |
| Processor ARK ID | 48768 |
| Intel Rapid Storage Technology | No |
| CPU configuration (max) | 2 |
| Power | |
| Power supply type | AC |
| Number of power supply units | 1 |
| Power requirements | 100 – 127 V |
| Power supply input frequency | 50 – 60 Hz |
| Power supply | 460 W |
| Operational conditions | |
| Storage temperature (T-T) | 5 – 45 °C |
| Operating relative humidity (H-H) | 20 – 80% |
| Storage relative humidity (H-H) | 8 – 80% |
| Operating temperature (T-T) | 10 – 35 °C |
| Operating altitude | 0 – 915 m |
| Certificates | |
| Certification | CE, CISPR 22, TUV-GS |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Rapid Storage Technology | No |
| CPU configuration (max) | 2 |
| Chassis type | Rack (2U) |
| Weight & dimensions | |
| Width | 443.6 mm |
| Weight | 25 kg |
| Height | 85.4 mm |
| Depth | 698 mm |
| Other features | |
| Graphics card memory type | GDDR2 |
| Graphics card family | Matrox |
| Graphics card | G200eV |
| CPU configuration (max) | 2 |
