| Data transmission |
| Ethernet LAN data rates |
10,100,1000,2500,5000 Mbit/s |
| Maximum data transfer rate |
4800 Mbit/s |
| Performance |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Automatic channel selection |
Yes |
| Auto MDI/MDI-X |
Yes |
| Reset button |
Yes |
| Bandwidth |
160 GHz |
| Spread spectrum method |
DSSS |
| Frequency band |
2.4 – 7.125 GHz |
| VLAN support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz |
| Ethernet LAN data rates |
10,100,1000,2500,5000 Mbit/s |
| Channels quantity |
3 channels |
| Channel bandwidth |
160 MHz |
| Maximum data transfer rate |
4800 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Wireless LAN features |
| Frequency band |
2.4 – 7.125 GHz |
| Channels quantity |
3 channels |
| Network |
| Spread spectrum method |
DSSS |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz |
| Bandwidth |
| Bandwidth |
160 GHz |
| Channel bandwidth |
160 MHz |
| Management features |
| VLAN support |
Yes |
| Features |
| 6 GHz |
Yes |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Automatic channel selection |
Yes |
| Auto MDI/MDI-X |
Yes |
| Bandwidth |
160 GHz |
| Spread spectrum method |
DSSS |
| Frequency band |
2.4 – 7.125 GHz |
| VLAN support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz |
| Ethernet LAN data rates |
10,100,1000,2500,5000 Mbit/s |
| Channels quantity |
3 channels |
| Channel bandwidth |
160 MHz |
| Maximum data transfer rate |
4800 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
| Maximal-Ratio Combining (MRC) |
Yes |
| Dynamic Frequency Selection (DFS) |
Yes |
| Data unit aggregation |
A-MPDU, A-MSDU |
| Cyclic Shift Diversity (CSD) |
Yes |
| Cyclic Delay Diversity (CDD) |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2400 Mbit/s |
| Maximum data transfer rate (6 GHz) |
4800 Mbit/s |
| Bluetooth Low Energy (BLE) |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| BeamForming |
Yes |
| Security |
| Security algorithms |
WPA, WPA2, WPA3 |
| Access Control List (ACL) |
Yes |
| Ports & interfaces |
| USB connector type |
USB Type-A |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| DC-in jack |
Yes |
| Power |
| Power consumption (max) |
22.7 W |
| Power consumption (typical) |
20.2 W |
| Power over Ethernet (PoE) |
Yes |
| DC voltage range |
12 V |
| Design |
| Placement |
Ceiling |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Status, System |
| Antenna |
| Antenna type |
Internal |
| Antenna gain level (max) |
4.8 dBi |
| Antenna direction type |
Omni-directional |
| Technical details |
| Reset button |
Yes |
| Sustainability compliance |
Yes |
| Compliance certificates |
Federal Communications Commission (FCC) |
| Certificates |
| Compliance certificates |
Federal Communications Commission (FCC) |
| Indication |
| LED indicators |
Status, System |
| Software |
| Access Control List (ACL) |
Yes |
| Maximal-Ratio Combining (MRC) |
Yes |
| Dynamic Frequency Selection (DFS) |
Yes |
| Data unit aggregation |
A-MPDU, A-MSDU |
| Cyclic Shift Diversity (CSD) |
Yes |
| Cyclic Delay Diversity (CDD) |
Yes |
| Weight & dimensions |
| Width |
260 mm |
| Depth |
260 mm |
| Weight |
1.8 kg |
| Height |
60 mm |
| Package width |
285 mm |
| Package depth |
285 mm |
| Package height |
95 mm |
| Package weight |
2.3 kg |
| Packaging data |
| Package width |
285 mm |
| Package depth |
285 mm |
| Package height |
95 mm |
| Package weight |
2.3 kg |
| Packaging content |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 95% |
| Operating temperature (T-T) |
0 – 50 °C |
| Storage temperature (T-T) |
-25 – 55 °C |
| Storage relative humidity (H-H) |
10 – 100% |
| Sustainability |
| Sustainability compliance |
Yes |
| Logistics data |
| Quantity per pack |
1 pc(s) |
