| Technical Information |
|
| Diagonal Viewing Size |
604.70 mm / 23.80 inches |
| Preset Display Area (H x V) |
527.04 mm x 296.46 mm / 20.75″ x 11.67″ / 156,246.27 mm² (242.15 inches²) |
| Panel Type |
IPS |
| Display Screen Coating |
Anti-Glare with 3H hardness |
| Maximum Preset Resolution |
1920 x 1080 at 120 Hz |
| Viewing Angle |
178° vertical / 178° horizontal |
| Pixel Pitch |
0.2745 mm x 0.2745 mm |
| Pixel Per Inch (PPI) |
92.53 |
| Contrast Ratio |
1000 to 1 (typical) |
| Aspect Ratio |
16:9 |
| Backlight Technology |
LED Edgelight System |
| Brightness |
250 cd/m² (typical) |
| Response Time |
8 ms (Normal) / 5 ms (Fast) |
| HDR Ready |
No |
| Ambient Light Sensor |
Yes, auto brightness and color temperature adjustment |
| Color Support |
16.7 million colors |
| Color Gamut |
100% sRGB, 100% BT.709, 85% DCI-P3, Delta E < 2 (average) (sRGB and BT.709) |
| Interfaces |
|
| DisplayPort 1.4 |
1 x DisplayPort 1.4 (DRR for Microsoft Windows) (HDCP 1.4) |
| HDMI |
1 x HDMI (HDCP 1.4) (supports up to FHD 1920 x 1080 120Hz TMDS as per specified in HDMI 1.4) |
| DisplayPort 1.4 (Out) |
1 x DisplayPort 1.4 (Out) with MST (HDCP 1.4) |
| USB Type-C Upstream Port |
1 x USB Type-C upstream port (data only, SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) |
| USB Type-A Downstream Port |
2 x USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) |
| Audio Line-Out Port |
1 x audio line-out port |
| Quick Access Ports |
1 x USB Type-C downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with power charging (15W) |
| USB Type-A Downstream Port |
1 x USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with BC1.2 power charging |
| Adjustability |
|
| Height Adjustable |
150 mm |
| Tilt |
-5°/+21° |
| Swivel |
-45°/+45° |
| Pivot |
-90°/+90° |
| PbP / PiP |
No |
| KVM |
No |
| Daisy Chain Availability |
Yes |
| Audio Output |
1 x Audio line-out |
| Built-in Speaker |
No |
| Security |
|
| Security Lock Slot |
Yes (cable lock sold separately) |
| Anti-theft Stand Lock Slot |
Yes (to lock stand to monitor using screw) |
| Compliant Standards |
ENERGY STAR certified monitor, EPEAT registered, RoHS-compliant, TCO Certified, BFR/PVC free monitor, Arsenic-free glass, Mercury-free panel |
| Flat Panel Mount Interface |
VESA mounting holes (100 mm x 100 mm – behind attached VESA Cover) |
| What’s Included |
Monitor, Stand Riser, Stand Base, Quick setup guide, Safety, Environmental and Regulatory Information, Factory calibration report |
| Cables Included |
1 x Power cable, 1 x DisplayPort 1.4 cable – 1.8 m, 1 x USB Type-A to USB Type-C Gen 2 cable – 1 m |
| Power |
|
| Voltage Required |
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typical) |
| Power Consumption (On mode) |
13.7 W |
| Power Consumption (Max) |
72.0 W |
| Power Consumption Standby |
0.5 W |
| Power Consumption (Off Mode) |
0.3 W |
| Dell Display Manager Compatibility |
Yes, Easy Arrange, Other key features |
| Environmental |
|
| Temperature Range |
Operating: 0°C to 40°C (32°F to 104°F) / Non-operating: –20°C to 60°C (–4°F to 140°F) – Storage and Shipping |
| Humidity Range |
Operating: 10% to 80% (non-condensing) / Non-Operating: 5% to 90% (non-condensing) – Storage and Shipping |
| Altitude |
Operating: 5000 m (16404 ft) max / Non-Operating: 12192 m (40000 ft) max |
| Physical Characteristics |
|
| Height with Stand |
364.00 mm ~ 496.53 mm |
| Width with Stand |
538.64 mm |
| Depth with Stand |
181.75 mm |
| Height without Stand |
311.21 mm |
| Width without Stand |
538.64 mm |
| Depth without Stand |
49.10 mm |
| Weight (Panel Only for VESA Mount) |
3.52 kg |
| Weight (With Stand and Cables) |
5.38 kg |
| Weight (With Packaging) |
7.92 kg |
