Description
Specifications
Screen Size Class | 22″ (55.88 cm) |
Viewable Screen Size | 21.50″ (54.61 cm) |
Screen Mode | Full HD |
Panel Technology | Vertical Alignment (VA) |
Response Time | 5 ms (8ms GTG / 5ms GTG Fast) |
Aspect Ratio | 16:9 |
Pixel Pitch | 0.2493 mm x 0.2410 mm |
Viewing Angle (H/V) | 178° / 178° |
Mount Type | Panel Mount |
Backlight Technology | LED Edgelight System |
HDCP Supported | Yes |
Tilt Angle | -5° to 21° |
Features | Narrow Bezel, Cable Lock Slot, Security Lock, Anti-glare, Eye Comfort Technology |
Horizontal Frequency | 30–82 kHz (VGA), 30–111 kHz (HDMI) |
Vertical Frequency | 50–76 Hz (VGA), 50–100 Hz (HDMI) |
Stand Adjustments | Tilt |
Stand Included | Yes |
Glass Hardness | 3H |
Video | |
Max Resolution | 1920 × 1080 |
Refresh Rate | 100 Hz |
Colours Supported | 16.7 Million Colours |
Contrast Ratio (Native) | 3,000:1 |
Brightness | Not specified |
Color Gamut | 72% NTSC (CIE 1931) |
Pixel Density (PPI) | 102 |
Ports & Interfaces | |
HDMI | 1× HDMI (HDCP 1.4, FHD 1920×1080 @ 100Hz) |
VGA | 1 |
Environmental Conditions | |
Operating Temp | 0°C to 40°C |
Storage Temp | -20°C to 60°C |
Operating Humidity | 10% to 80% (Non-condensing) |
Storage Humidity | 5% to 90% (Non-condensing) |
Max Operating Altitude | 5 km (196,800″) |
Max Storage Altitude | 12.19 km (480,000″) |
Power Description | |
Input Voltage Range | 100V–240V AC |
Operating Power | 11.70 W |
Standby Power | 0.3 W |
Off-Mode Power | 0.3 W |
Max Power Consumption | 20.70 W |
Frequency | 50 / 60 Hz |
Voltage Current | 1 Ah |
Physical Characteristics | |
VESA Mount Compatible | Yes (100 x 100) |
Monitor Dimensions (H×W×D) | 286.48 × 492.86 × 211.80 mm |
With Stand (H×W×D) | 395.75 × 492.86 × 211.80 mm |
Bezel Width (Left/Right) | 7.05 mm |
Weight (Net / With Stand) | 2.23 kg / 2.96 kg |
Stand (H×W×D) | 181.60 × 219.90 × 211.80 mm |
Miscellaneous | |
Package Contents | Monitor, Stand, Cleaning Cloth, Drivers & Docs, Quick Start Guide, Safety Info, Factory Calibration Report |
Cables Included | 1.8m HDMI Cable, Power Cable |
Energy Star | Yes (ENERGY STAR 8.0) |
TAA Compliant | Yes |
TCO Certified | Yes |
Energy Compliance | ErP Lot 5, MEPS |
