Description
Specifications
Power Supply Rated Maximum | 1025W |
Total Output BTU (Note: 1000 BTU per hr = 293 W) | 3497 BTU/hr, 1025W |
Input-Voltage Range and Frequency
(Note: ±10% of “Input-Voltage Range”) |
115-240VAC,
50-60 Hz |
Input Current | 12-6A |
Output Ratings | 12V @ 20.83A
-54V @ 14.6A |
Output Holdup Time | 10 ms minimum @ 102.5VAC |
Power-Supply Input Receptacles | IEC 320-C16
(IEC60320-C16) |
Power Cord Rating | 13A |
Physical Specifications | (H x W x D): 1.58 X 3.75 X 13.25 in (4.0 x 9.5 x 33.7 cm)
Weight: 3.55 lb (1.61 kg) |
Operating Temperature | For the operating temperature ranges at various altitudes of AC and DC power supply module powered switches, see Table 1. |
Storage Temperature | -40 to 158°F (-40 to 70°C) |
Relative Humidity Operating and Nonoperating Noncondensing | 5 to 96% noncondensing |
Altitude | 16,400 ft. (5,000 meters) |
