Technical details |
Rack mounting |
Yes |
Form factor |
1U |
Concurrent connections |
2000000 |
Harmonized System (HS) code |
85176990 |
Data transmission |
Firewall throughput |
4750 Mbit/s |
VPN throughput |
1500 Mbit/s |
IPS/IDS throughput |
4750 Mbit/s |
Maximum firewall connections per second |
24000 |
Firewall throughput |
4.75 Gbit/s |
VPN throughput |
1.5 Gbit/s |
Performance |
Noise level |
56 dB |
Concurrent connections |
2000000 |
Network |
Maximum Number of VPN connections supported |
7500 |
Number of VLANs |
1024 |
Security |
Content filtering |
280000000 URL |
Hard drive |
Total storage capacity |
200 GB |
Number of HDDs installed |
1 |
Ports & interfaces |
SFP module slots quantity |
12 |
Connectivity technology |
Wired |
USB 2.0 ports quantity |
1 |
Serial ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
12 |
Storage |
Total storage capacity |
200 GB |
Number of HDDs installed |
1 |
Sound emission |
Noise level |
56 dB |
Design |
Rack mounting |
Yes |
Form factor |
1U |
Power |
AC input voltage |
100-240 V |
AC input frequency |
50 – 60 Hz |
Input current |
6 A |
Power supply |
400 W |
Number of power supply units |
1 |
Logistics data |
Harmonized System (HS) code |
85176990 |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-20 – 65 °C |
Operating relative humidity (H-H) |
10 – 85% |
Storage relative humidity (H-H) |
5 – 95% |
Operating altitude |
0 – 3048 m |
Non-operating altitude |
0 – 12192 m |
Weight & dimensions |
Dimensions (WxDxH) |
429 x 502 x 44 mm |
Weight |
9.6 kg |
Other features |
Firewall throughput |
4750 Mbit/s |
VPN throughput |
1500 Mbit/s |
