| Specification |
| Network |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3x |
| Jumbo frames support |
Yes |
| Ethernet LAN data rates |
10000 Mbit/s |
| Quality of Service (QoS) support |
Yes |
| Number of VLANs |
4000 |
| Access Control List (ACL) |
Yes |
| Technical details |
| Bandwidth |
80 Gbit/s |
| Operating temperature (T-T) |
32 – 104 °F |
| Management platform |
ETHERLIKE-MIB (RFC 1643), IF-MIB (RFC 1573), Bridge MIB (RFC 1493), CISCO-STACK-MIB, CISCO-VTP-MIB, CISCO-CDP-MIB, RMON MIB (RFC 1757), CISCO-PAGP-MIB, CISCO-STP-EXTENSIONS-MIB, CISCO-VLAN-BRIDGE-MIB, CISCO-VLAN-MEMBERSHIP-MIB, ENTITY-MIB (RFC 2037), HC-RMON, RFC1213-MIB (MIB-II), SMON-MIB |
| MAC address table |
128000 entries |
| Ethernet LAN data rates |
10000 Mbit/s |
| Compatibility |
Cisco Catalyst 6800 |
| Buffer size per port |
2.5 MB |
| Data transmission |
| Bandwidth |
80 Gbit/s |
| Switching capacity |
80 Gbit/s |
| Number of VLANs |
4000 |
| MAC address table |
128000 entries |
| Forwarding rate |
60 Mpps |
| Data transfer rate |
10 Gbit/s |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
8 |
| Performance |
| Compatibility |
Cisco Catalyst 6800 |
| Buffer size per port |
2.5 MB |
| Ergonomics |
| Connectivity LEDs |
Yes |
| Management features |
| Quality of Service (QoS) support |
Yes |
| Management platform |
ETHERLIKE-MIB (RFC 1643), IF-MIB (RFC 1573), Bridge MIB (RFC 1493), CISCO-STACK-MIB, CISCO-VTP-MIB, CISCO-CDP-MIB, RMON MIB (RFC 1757), CISCO-PAGP-MIB, CISCO-STP-EXTENSIONS-MIB, CISCO-VLAN-BRIDGE-MIB, CISCO-VLAN-MEMBERSHIP-MIB, ENTITY-MIB (RFC 2037), HC-RMON, RFC1213-MIB (MIB-II), SMON-MIB |
| Access Control List (ACL) |
Yes |
| Security |
| Access Control List (ACL) |
Yes |
| Power |
| Power consumption (typical) |
303.68 W |
| Operational conditions |
| Storage temperature (T-T) |
-40 – 75 °C |
| Operating temperature (T-T) |
32 – 104 °F |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| Operating altitude |
-150 – 3000 m |
| Certificates |
| Safety |
UL 60950-1, CAN/CSA C22.2 No. 60950, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, IEC 60825 Class 1, EN 60825 Class 1, 21CFR 1040 |
| Electromagnetic compatibility |
FCC Part 15 (CFR 47) Class A, ICES-003 Class A, VCCI Class A, EN55022 Class A, EN55024, CISPR24, CISPR 22 Class A, AS/NZS CISPR 22 Class A, ETS 300 386, KN 22 Class A, EN 50082-1, EN61000-3-2, EN61000-3-3, EN61000-6-1, CNS13438 Class A, KN6100 -4 Series |
| Indication |
| Connectivity LEDs |
Yes |
| Weight & dimensions |
| Weight |
5 kg |
| Dimensions (WxDxH) |
391.1 x 416.5 x 43.9 mm |
|
