Ethernet LAN features |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Cabling technology |
10/100/1000Base-T(X) |
Ethernet LAN |
Yes |
Network |
Short Message Service (SMS) |
Yes |
Internal modem |
Yes |
Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ah, IEEE 802.3u |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Cabling technology |
10/100/1000Base-T(X) |
Supports ISDN connection |
No |
Ethernet LAN |
Yes |
Ethernet interface type |
Gigabit Ethernet |
Memory |
Flash memory |
1000 MB |
Internal memory |
1024 MB |
Performance |
Flash memory |
1000 MB |
Internal memory |
1024 MB |
Firmware upgradeable |
Yes |
WAN connection |
Ethernet WAN |
Yes |
DSL WAN |
No |
SIM card slot |
Yes |
Mobile network |
Mobile network generation |
4G |
Short Message Service (SMS) |
Yes |
4G bands supported |
800,900,1800,2100,2600 MHz |
UMTS bands supported |
850,900,1900,2100 MHz |
GSM bands supported |
800,900,1800,1900 MHz |
2G standards |
Edge, GPRS, GSM |
3G standards |
HSPA+, UMTS |
4G standard |
LTE |
DSL features |
Internal modem |
Yes |
Management features |
Firmware upgradeable |
Yes |
Web-based management |
Yes |
Reset button |
Yes |
Quality of Service (QoS) support |
Yes |
Ports & interfaces |
Serial ports quantity |
1 |
USB ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
4 |
DC-in jack |
Yes |
Protocols |
Routing protocols |
EIGRP, HSRP |
Management protocols |
SNMPv3, IGMPv3 |
Supported network protocols |
IPv4, IPv6, DNS, PPPoE, PPPoA, HTTPS, FTP, Telnet |
DHCP server |
Yes |
DHCP client |
Yes |
Technical details |
On/off switch |
Yes |
Firmware upgradeable |
Yes |
Supports ISDN connection |
No |
LED indicators |
Yes |
Product colour |
Black |
Security |
Firewall |
Yes |
Firewall security |
Cisco IOS |
Security algorithms |
3DES, AES, HTTPS, SNMP |
Features |
Flash memory |
1000 MB |
Internal memory |
1024 MB |
Electromagnetic compatibility |
EN55022/CISPR22, CFR 47 Part 15, ICES003, VCCI-V-3, AS/NZS CISPR22, CNS13438, EN300-386, EN61000-3-2, EN61000-3-3, and EN61000-6-1, EN55024/CISPR24, (EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11), and EN300-386 |
Certification |
UL 60950-1, 2nd edition CAN/CSA C22.2 No. 60950-1, 2nd edition EN 60950-1, 2nd edition CB to IEC 60950-1, 2nd edition with all group differences and national deviations |
Design |
On/off switch |
Yes |
LED indicators |
Yes |
Product colour |
Black |
Antenna |
Antenna type |
External |
Detachable antenna(s) |
Yes |
Antennas quantity |
2 |
Antenna gain level (max) |
9 dBi |
Antenna connector type |
TNC |
Power |
Power source type |
AC |
AC input voltage |
100 – 240 V |
AC input frequency |
50 – 60 Hz |
Power over Ethernet (PoE) |
Yes |
Operational conditions |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-25 – 65 °C |
Operating relative humidity (H-H) |
10 – 85% |
Storage relative humidity (H-H) |
5 – 95% |
Operating altitude |
0 – 3000 m |
Non-operating altitude |
0 – 4570 m |
Weight & dimensions |
Width |
325 mm |
Depth |
264 mm |
Height |
48 mm |
Weight |
2.54 kg |
Packaging data |
Quick start guide |
Yes |
Manual |
Yes |
Certificates |
Electromagnetic compatibility |
EN55022/CISPR22, CFR 47 Part 15, ICES003, VCCI-V-3, AS/NZS CISPR22, CNS13438, EN300-386, EN61000-3-2, EN61000-3-3, and EN61000-6-1, EN55024/CISPR24, (EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11), and EN300-386 |
Certification |
UL 60950-1, 2nd edition CAN/CSA C22.2 No. 60950-1, 2nd edition EN 60950-1, 2nd edition CB to IEC 60950-1, 2nd edition with all group differences and national deviations |
Packaging content |
Quick start guide |
Yes |
Manual |
Yes |
