Description
Device Type | Router |
Enclosure Type | Desktop – modular – 1U |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Routing Protocol | HSRP |
Features | NAT support, load balancing, MPLS support, IPv6 support, Access Control List (ACL) support, Quality of Service (QoS) |
Processor | 1 x Motorola PowerPC 7448 1.67 GHz |
RAM | 1 GB (installed) / 2 GB (max) – DDR SDRAM |
Flash Memory | 256 MB (installed) / 256 MB (max) |
DIMENSIONS & WEIGHT | |
---|---|
Width | 48.3 cm |
Depth | 42.9 cm |
Height | 4.4 cm |
Weight | 7.5 kg |
POWER | |
Power Device | Internal power supply – hot-plug |
Power Redundancy | Yes |
Installed Qty | 2 (installed) / 2 (max) |
ENVIRONMENTAL PARAMETERS | |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 – 90% |
EXPANSION / CONNECTIVITY | |
Interfaces | Management: 1 x 10Base-T/100Base-TX – RJ-45 Management: 1 x console – RJ-45 Management: 1 x auxiliary – RJ-45 2 x 10Base-T/100Base-TX/1000Base-T – RJ-45 USB: 1 x 4 pin USB Type A 4 x SFP (mini-GBIC) |
Expansion Slots | 1 (total) / 0 (free) x CompactFlash 1 (total) / 1 (free) x expansion slot 1 (total) / 0 (free) x memory |
Installed Modules Qty (Max) | 0 (installed) / 1 (max) |
