Description
GENERAL | |
---|---|
Device Type | Router |
Enclosure Type | Desktop, rack-mountable – modular – 1U |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Network / Transport Protocol | IPSec, L2TPv3 |
Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS |
Remote Management Protocol | SNMP, RMON |
Features | Firewall protection, VPN support, MPLS support, VLAN support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Quality of Service (QoS), Web Services Management Agent (WSMA), TR-069 Agent, NetFlow |
Compliant Standards | IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag, VCCI, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, CSA C22.2 No. 60950-1, AS/NZS 3548 Class A |
RAM | 512 MB (installed) / 512 MB (max) |
Flash Memory | 256 MB (installed) / 256 MB (max) |
DIMENSIONS & WEIGHT | |
Width | 34.3 cm |
Depth | 29.2 cm |
Height | 4.4 cm |
Weight | 5.4 kg |
MISCELLANEOUS | |
Rack Mounting Kit | Optional |
POWER | |
Power Device | Internal power supply |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Consumption Operational | 60 Watt |
ENVIRONMENTAL PARAMETERS | |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 – 85% |
EXPANSION / CONNECTIVITY | |
Interfaces | 2 x 10Base-T/100Base-TX/1000Base-T – RJ-45 Serial: 1 x console Management: 1 x console – mini-USB Type B Serial: 1 x auxiliary USB 2.0: 1 x 4 pin USB Type A |
Expansion Slots | 2 (total) / 2 (free) x EHWIC |
MANUFACTURER WARRANTY | |
Service & Support | Limited warranty – advance parts replacement – 1 year – response time: 10 days |
SOFTWARE / SYSTEM REQUIREMENTS | |
OS Provided | Cisco IOS Security |
