Specification |
Technical details |
Mounting |
DIN-rail |
Device type |
Cellular network router |
Data network |
2G, 3G, 4G |
Ethernet LAN features |
Ethernet LAN (RJ-45) ports |
3 |
Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
Ethernet LAN data rates |
100 Mbit/s |
Auto MDI/MDI-X |
Yes |
Ethernet LAN |
Yes |
Ethernet LAN interface type |
Fast Ethernet |
Cellular interface |
Number of SIM cards |
2 |
4G standard |
LTE |
Network |
Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
Design |
Mounting |
DIN-rail |
Housing material |
Aluminium, Plastic |
Device type |
Cellular network router |
Product colour |
Black |
Market positioning |
Industrial |
Reset button |
Yes |
LED indicators |
Yes |
Wireless LAN features |
Wi-Fi |
Yes |
Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Mobile network |
Number of SIM cards |
2 |
Data network |
2G, 3G, 4G |
Short Message Service (SMS) |
Yes |
4G standard |
LTE |
Ports & interfaces |
Ethernet LAN (RJ-45) ports |
3 |
Security |
Port forwarding |
Yes |
Security algorithms |
AES-CCMP, HTTPS, SSH, SSL/TLS, TKIP, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
Network address translation (NAT) |
Yes |
Firewall |
Yes |
DMZ support |
Yes |
Material |
Housing material |
Aluminium, Plastic |
Performance |
Processor frequency |
0.58 GHz |
RAM capacity |
128 GB |
RAM type |
DDR2 |
Management features |
Web-based management |
Yes |
Antenna |
Antenna type |
External |
Antennas quantity |
4 |
Power |
Power source type |
DC |
Operational conditions |
Operating temperature (T-T) |
-40 – 75 °C |
Operating relative humidity (H-H) |
10 – 90% |
Weight & dimensions |
Weight |
287 g |
Width |
110 mm |
Depth |
100 mm |
Height |
50 mm |
|
Meta Description |
4G/LTE (Cat 4), 3G, 2G, 2 SIM cards, IEEE 802.11b/g/n, Access Point (AP), Station (STA), 1 x WAN port, 3 x LAN ports, Europe, the Middle East, Africa |
